Relay, 4Pin, SPST, 10A, 24VAC

Omron Part No : G2R-1A-T-AC24

Flange Mount Relay, Coil Volts 24V AC, AC Contact Rating - Relay 10A @ 240V, DC Contact Rating - Relay 10A @ 28V, Number of Pins - Relay 4, Contact Form - Relay SPST-NO, Mounting - Relay Top Flange, Power Consumption - Relay 0.9 VA, Contact Material Silver Alloy, Status Indicator No, Electrical Connection 0.187 in Solder Terminals

  • Description
  • Specifications

Flange Mount Relay, Coil Volts 24V AC, AC Contact Rating - Relay 10A @ 240V, DC Contact Rating - Relay 10A @ 28V, Number of Pins - Relay 4, Contact Form - Relay SPST-NO, Mounting - Relay Top Flange, Power Consumption - Relay 0.9 VA, Contact Material Silver Alloy, Status Indicator No, Electrical Connection 0.187 in Solder Terminals


  • Item: Flange Mount Relay
  • Coil Volts: 24V AC
  • AC Contact Rating - Relay: 10A @ 240V
  • DC Contact Rating - Relay: 10A @ 28V
  • Number of Pins - Relay: 4
  • Power Consumption - Relay: 0.9 VA
  • Contact Form - Relay: SPST-NO
  • Mounting - Relay: Top Flange
  • Contact Material: Silver Alloy
  • HP @ 120V: 1/3 hp
  • Electrical Connection: 0.187 in Solder Terminals
  • Pins: 4
  • Body Width - Relay: 1.2 in
  • Body Height - Relay: 1.16 in
  • Contact Rating: 10A @ 250VAC/30VDC
  • Standards: CSA Certified, UL Listed
  • Body Depth - Relay: 0.46 in
