Open Power Relay, 5 Pin, 240VAC, SPDT

Omron Part No : MGN1C-AC240

Item - Relay: Open Power Relay

Coil Volts: 240V AC

AC Contact Rating - Relay: 30A @ 240V

  • Description
  • Specifications

Open Power Relay, Coil Volts 240V AC, AC Contact Rating - Relay 30A @ 240V, DC Contact Rating - Relay 30A @ 28V, Number of Pins - Relay 5, Contact Form - Relay SPDT, Mounting - Relay Surface, Power Consumption - Relay 9.5 VA, Contact Material Silver Alloy, Electrical Connection - Power Relay Screw


  • Coil Volts: 240V AC
  • AC Contact Rating - Relay: 30A @ 240V
  • DC Contact Rating - Relay: 30A @ 28V
  • Number of Pins - Relay: 5
  • Contact Form - Relay: SPDT
  • Mounting - Relay: Surface
  • Power Consumption - Relay: 9.5 VA
  • Contact Material: Silver Alloy
  • Electrical Connection - Power Relay: Screw
  • Number of Poles: 1
  • Item: Open Power Relay
  • Body Width - Relay: 2.5 in
  • Hz: 50/60
  • Features: 600V AC, Class F Coil Insulation System for 155 Degrees C (311 Degrees F), Coil Molded in DuPont Rynite(R) for Environmental Protection, Rugged Construction Rivets Terminals to Base, Short Circuit Current Rating (SCCR) of 5kA
  • Contact Form: SPDT
