Photoelectric-Sensor-Rectangl-Thru-Beam-O5E502

Photoelectric Sensor, Rectangl, Thru-Beam

IFM Part No : O5E502

Item: Photoelectric Sensor

IP Rating: 67

Sensing Method - Rectangular Photoelectric Sensor: Through Beam Receiver

Description
Specifications

Photoelectric Sensor, Shape - Rectangular Photoelectric Sensor Rectangular, Sensing Method - Rectangular Photoelectric Sensor Through Beam Receiver, Power Requirement - Rectangular Photoelectric Sensor 10 to 36V DC, Output Circuit Type - Rectangular Photoelectric Sensor NPN, Operating Mode - Photoelectric Sensor Selectable Light On/Dark On, Max. Sensing Distance - Rectangular Photoelectric Sensor 25.0 m, Electrical Connection - Rectangular Photoelectric Sensor 4-Pin M12 Male Connector

Item: Photoelectric Sensor
IP Rating: 67
Sensing Method - Rectangular Photoelectric Sensor: Through Beam Receiver
Circuit Type: NPN
Power Requirement - Rectangular Photoelectric Sensor: 10 to 36V DC
Output Circuit Type - Rectangular Photoelectric Sensor: NPN
Width: 18.20mm
Operating Mode - Photoelectric Sensor: Selectable Light On/Dark On
Depth: 70.30mm
Max. Sensing Distance - Rectangular Photoelectric Sensor: 25 m
Max. Load Current: 200 mA
Electrical Connection - Rectangular Photoelectric Sensor: 4-Pin M12 Male Connector
Operating Frequency: 1,000 Hz
Height - Rectangular Photoelectric Sensor: 47 mm
Electrical Connection: Quick Disconnect M12 Connector
Features: PMMA Lens, Reverse Polarity and Overload Protection
Operation Mode: Selectable Light On/Dark On
Length: 46.80mm
Operating Temp. Range: -25 Degrees to 60 Degrees C
Body Material: Polyamides
Depth - Rectangular Photoelectric Sensor: 70 mm
NEMA Rating: Not Rated
Power Requirement: 10 to 36VDC
Shape: Rectangular
Light Source: Red LED
Width - Rectangular Photoelectric Sensor: 18 mm
Max. Sensing Distance: 25m
Sensing Method: Through Beam Receiver

Photoelectric Sensor, Rectangl, Thru-Beam
