Solid State Relay, 4 to 32VDC, 50A

schneider Part No : SSP3A250BDRT

Item - Relay: Solid State Relay

Input or Control Voltage: 4 to 32V DC

Output or Controlled Voltage Range: 48 to 530V AC

  • Description
  • Specifications

Solid State Relay, Input or Control Voltage 4 to 32V DC, Output or Controlled Voltage Range 48 to 530V AC, Max. Output Amps w/Heat Sink 50, Heat Sink Not Included, Switch Type SCR, Contact Form - Relay (3) SPST-NO, Relay Turns On At Instantaneous/Random, Input Power Consumption (Burden) 1.1W, Mounting - Relay Surface, Finger Safe Yes


  • Input or Control Voltage: 4 to 32V DC
  • Output or Controlled Voltage Range: 48 to 530V AC
  • Max. Output Amps w/Heat Sink: 50
  • Heat Sink: Not Included
  • Switch Type: SCR
  • Contact Form - Relay: (3) SPST-NO
  • Relay Turns On At: Instantaneous/Random
  • Input Power Consumption (Burden): 1.1W
  • Mounting - Relay: Surface
  • Input Voltage: 4 to 32VDC
  • Voltage Output: 48 to 530VAC
  • Item: Solid State Relay
  • Body Height - Relay: 1.4 in
  • Case Color: Dark Gray
  • Turns On At: Random Cross
  • Phase: 3
  • Max. Output w/Heat Sink: 50A
  • Body Width - Relay: 4.0 in
  • Body Depth - Relay: 3.14 in
  • Max. Output Amps Without Heat Sink: Not Recommended
  • Overall Height - Relay: 1.4 in
  • Mounting: Flange
  • Finger Safe: Yes
  • Input or Control Voltage Range: 4 to 32VDC
  • Green Environmental Attribute: Does not Contain Formaldehyde
