Solid State Relay, 3 to 32VDC, 50A

schneider Part No : 6250AXXSZS-DC3

Item - Relay: Solid State Relay

Input or Control Voltage: 3 to 32V DC

Output or Controlled Voltage Range: 24 to 280V AC

Solid State Relay, Input or Control Voltage 3 to 32V DC, Output or Controlled Voltage Range 24 to 280V AC, Max. Output Amps w/Heat Sink 50, Heat Sink Not Included, Switch Type SCR, Contact Form - Relay SPST-NO, Relay Turns On At Zero Crossing, Input Power Consumption (Burden) 0.1W, Mounting - Relay Surface, Finger Safe Yes


  • Input or Control Voltage: 3 to 32V DC
  • Output or Controlled Voltage Range: 24 to 280V AC
  • Max. Output Amps w/Heat Sink: 50
  • Case Color: Gray
  • Mounting - Relay: Surface
  • Contact Form - Relay: SPST-NO
  • Item: Solid State Relay
  • Input Power Consumption (Burden): 0.1W
  • Relay Turns On At: Zero Crossing
  • Voltage Output: 24 to 280VAC
  • Body Height - Relay: 1.4 in
  • Mounting: Surface
  • Max. Output w/Heat Sink: 50A
  • Body Depth - Relay: 2.3 in
  • Finger Safe: Yes
