Photoelectric-Sensor-Rectangular-NPN-E3X-MDA11

Photoelectric Sensor, Rectangular, NPN

Omron Part No : E3X-MDA11

Photoelectric Sensor, Shape - Rectangular Photoelectric Sensor Rectangular, Power Requirement - Rectangular Photoelectric Sensor 12 to 24V DC, Output Circuit Type - Rectangular Photoelectric Sensor NPN, Operating Mode - Photoelectric Sensor Selectable Light On/Dark On, Max. Sensing Distance - Rectangular Photoelectric Sensor Dependent on Fiber Cable Attached, Electrical Connection - Rectangular Photoelectric Sensor 2m Cable, Height - Rectangular Photoelectric Sensor 32 mm

Description
Specifications

Item: Photoelectric Sensor
Circuit Type: NPN
IP Rating: 50
Power Requirement - Rectangular Photoelectric Sensor: 12 to 24V DC
Output Circuit Type - Rectangular Photoelectric Sensor: NPN
Width: 0.39"
Operating Mode - Photoelectric Sensor: Selectable Light On/Dark On
Depth: 2.75"
Max. Sensing Distance - Rectangular Photoelectric Sensor: Dependent on Fiber Cable Attached
Max. Load Current: 50 mA
Electrical Connection - Rectangular Photoelectric Sensor: 2m Cable
Height - Rectangular Photoelectric Sensor: 32 mm
Electrical Connection: 2m cable
Depth - Rectangular Photoelectric Sensor: 70 mm
Operating Temp. Range: -25 Degrees to 55 Degrees C
Features: Output Short-Cut And Output Reverse Polarity Protection, Surge Suppressor
Width - Rectangular Photoelectric Sensor: 10 mm
Shape: Rectangular
Body Material: PBT
Operation Mode: Selectable Light On/Dark On
Response Time: 0.1 msec
Length: 1.26"
Power Requirement: 12 to 24VDC
Light Source: Red LED

Photoelectric Sensor, Rectangular, NPN
