Photoelectric Sensor, Rectangular, Diffuse

Omron Part No : E3SCD61

Item: Photoelectric Sensor

Circuit Type: NPN/PNP

IP Rating: 67

Description
Specifications

Photoelectric Sensor, Shape - Rectangular Photoelectric Sensor Rectangular, Sensing Method - Rectangular Photoelectric Sensor Diffuse, Power Requirement - Rectangular Photoelectric Sensor 10 to 30V DC, Output Circuit Type - Rectangular Photoelectric Sensor NPN/PNP, Operating Mode - Photoelectric Sensor Selectable Light On/Dark On, Max. Sensing Distance - Rectangular Photoelectric Sensor 700 mm, Electrical Connection - Rectangular Photoelectric Sensor 2m Cable

Item: Photoelectric Sensor
Circuit Type: NPN/PNP
IP Rating: 67
Sensing Method - Rectangular Photoelectric Sensor: Diffuse
Power Requirement - Rectangular Photoelectric Sensor: 10 to 30V DC
Output Circuit Type - Rectangular Photoelectric Sensor: NPN/PNP
Width: 0.91"
Depth: 2.25"
Operating Mode - Photoelectric Sensor: Selectable Light On/Dark On
Max. Sensing Distance - Rectangular Photoelectric Sensor: 700 mm
Max. Load Current: 100 mA
Electrical Connection - Rectangular Photoelectric Sensor: 2m Cable
Height - Rectangular Photoelectric Sensor: 20 mm
Electrical Connection: 2m cable
Sensing Method: Diffuse
Length: 0.80"
Max. Sensing Distance: 700mm
Features: Output Short-Cut And Output Reverse Polarity Protection, Surge Suppressor
Footnotes: 3,4
Power Requirement: 10 to 30VDC
NEMA Rating: 4X, 6P
Operating Temp. Range: -25 Degrees to 55 Degrees C
Operation Mode: Selectable Light On/Dark On
Depth - Rectangular Photoelectric Sensor: 57 mm
Body Material: Die Cast Zinc
Width - Rectangular Photoelectric Sensor: 23 mm
Light Source: Infrared LED
Response Time: 1.0 msec
Shape: Rectangular
Standards: CE Approval

Photoelectric Sensor, Rectangular, Diffuse
