Photoelectric-Sensor-Rectangular-Diffuse-E3ZM-D62 2M

Photoelectric Sensor, Rectangular, Diffuse

Omron Part No : E3ZM-D62 2M

Item: Photoelectric Sensor

Circuit Type: NPN

Sensing Method - Rectangular Photoelectric Sensor: Diffuse

Description
Specifications

Photoelectric Sensor, Shape - Rectangular Photoelectric Sensor Rectangular, Sensing Method - Rectangular Photoelectric Sensor Diffuse, Power Requirement - Rectangular Photoelectric Sensor 10 to 30V DC, Output Circuit Type - Rectangular Photoelectric Sensor NPN, Operating Mode - Photoelectric Sensor Selectable Light On/Dark On, Max. Sensing Distance - Rectangular Photoelectric Sensor 1.0 m, Electrical Connection - Rectangular Photoelectric Sensor 2m Cable

Item: Photoelectric Sensor
Circuit Type: NPN
Sensing Method - Rectangular Photoelectric Sensor: Diffuse
IP Rating: 67, 69K
Power Requirement - Rectangular Photoelectric Sensor: 10 to 30V DC
Output Circuit Type - Rectangular Photoelectric Sensor: NPN
Width: 0.43"
Depth: 0.83"
Operating Mode - Photoelectric Sensor: Selectable Light On/Dark On
Max. Sensing Distance - Rectangular Photoelectric Sensor: 1 m
Max. Load Current: 100 mA
Electrical Connection - Rectangular Photoelectric Sensor: 2m Cable
Electrical Connection: 2m cable
Height - Rectangular Photoelectric Sensor: 32 mm
Width - Rectangular Photoelectric Sensor: 11 mm
Sensing Method: Diffuse
Operating Temp. Range: -25 Degrees to 55 Degrees C
Shape: Rectangular
Light Source: Infrared LED
Body Material: 316L Stainless Steel
Operation Mode: Selectable Light On/Dark On
Power Requirement: 10 to 30VDC
Standards: CE Approval
Footnotes: 4
Features: Output Short-Cut And Output Reverse Polarity Protection, Surge Suppressor
Length: 1.26"
Response Time: 1.0 msec
Depth - Rectangular Photoelectric Sensor: 21 mm

Photoelectric Sensor, Rectangular, Diffuse
