Photoelectric-Sensor-Rectangular-Diffuse-E3Z-D82

Photoelectric Sensor, Rectangular, Diffuse

Omron Part No : E3Z-D82

Item: Photoelectric Sensor

Circuit Type: PNP

IP Rating: 67

Description
Specifications

Photoelectric Sensor, Shape - Rectangular Photoelectric Sensor Rectangular, Sensing Method - Rectangular Photoelectric Sensor Diffuse, Power Requirement - Rectangular Photoelectric Sensor 12 to 24V DC, Output Circuit Type - Rectangular Photoelectric Sensor PNP, Operating Mode - Photoelectric Sensor Selectable Light On/Dark On, Max. Sensing Distance - Rectangular Photoelectric Sensor 1.0 m, Electrical Connection - Rectangular Photoelectric Sensor 2m Cable

Item: Photoelectric Sensor
Circuit Type: PNP
IP Rating: 67
Sensing Method - Rectangular Photoelectric Sensor: Diffuse
Power Requirement - Rectangular Photoelectric Sensor: 12 to 24V DC
Width: 0.41"
Output Circuit Type - Rectangular Photoelectric Sensor: PNP
Depth: 0.79"
Operating Mode - Photoelectric Sensor: Selectable Light On/Dark On
Max. Sensing Distance - Rectangular Photoelectric Sensor: 1 m
Max. Load Current: 100 mA
Electrical Connection - Rectangular Photoelectric Sensor: 2m Cable
Height - Rectangular Photoelectric Sensor: 30 mm
Electrical Connection: 2m cable
Max. Sensing Distance: 1m
Body Material: PBT
Response Time: 1.0 msec
Light Source: Infrared LED
Power Requirement: 12 to 24VDC
Width - Rectangular Photoelectric Sensor: 10 mm
Sensing Method: Diffuse
Shape: Rectangular
Depth - Rectangular Photoelectric Sensor: 20 mm
Features: Output Short Circuit and Power Supply Reverse Polarity Protection
Operating Temp. Range: -25 Degrees to 55 Degrees C
Standards: CE Approval
Operation Mode: Selectable Light On/Dark On
Length: 1.20"

Photoelectric Sensor, Rectangular, Diffuse
