Photoelectric-Sensor-Rectangle-Thru-Beam-E3SCT11

Photoelectric Sensor, Rectangle, Thru-Beam

Omron Part No : E3SCT11

Item: Photoelectric Sensor

IP Rating: 67

Sensing Method - Rectangular Photoelectric Sensor: Through Beam Set

Description
Specifications

Photoelectric Sensor, Shape - Rectangular Photoelectric Sensor Rectangular, Sensing Method - Rectangular Photoelectric Sensor Through Beam Set, Power Requirement - Rectangular Photoelectric Sensor 10 to 30V DC, Output Circuit Type - Rectangular Photoelectric Sensor NPN/PNP, Operating Mode - Photoelectric Sensor Selectable Light On/Dark On, Max. Sensing Distance - Rectangular Photoelectric Sensor 30.0 m, Electrical Connection - Rectangular Photoelectric Sensor 5m Cable

IP Rating: 67
Sensing Method - Rectangular Photoelectric Sensor: Through Beam Set
Circuit Type: NPN/PNP
Power Requirement - Rectangular Photoelectric Sensor: 10 to 30V DC
Width: 0.91"
Output Circuit Type - Rectangular Photoelectric Sensor: NPN/PNP
Operating Mode - Photoelectric Sensor: Selectable Light On/Dark On
Depth: 1.97"
Max. Load Current: 100 mA
Max. Sensing Distance - Rectangular Photoelectric Sensor: 30.0 m
Electrical Connection - Rectangular Photoelectric Sensor: 5m Cable
Electrical Connection: 5m Cable
Height - Rectangular Photoelectric Sensor: 20 mm
Depth - Rectangular Photoelectric Sensor: 50 mm
Light Source: Infrared LED
Standards: CE Approval
NEMA Rating: 4X, 6P
Max. Sensing Distance: 30m
Width - Rectangular Photoelectric Sensor: 23 mm
Features: Output Short-Cut And Output Reverse Polarity Protection, Surge Suppressor
Body Material: Die Cast Zinc
Shape: Rectangular
Power Requirement: 10 to 30VDC
Operating Temp. Range: -25 Degrees to 55 Degrees C
Response Time: 1.0 msec
Footnotes: 3,4
Operation Mode: Selectable Light On/Dark On
Sensing Method: Through Beam
Length: 0.80"v

Photoelectric Sensor, Rectangle, Thru-Beam
