Logic-Controller-100-to-240VAC-TM241CE24R

Logic Controller, 100 to 240VAC

schneider Part No : TM241CE24R

Item: Logic Controller

Input Voltage: 100 to 240V AC

Output Type: Relay

Description
Specifications

Logic Controller, Input Voltage 100 to 240V AC, Output Type Relay, 2.0 A Amps, Ethernet RJ45, Non isolated serial link serial 1 RJ45 RS232/RS485, Non isolated serial link serial 2 removable screw terminal block RS485, USB port mini B USB 2.0 Slots, Number of Inputs 14, Number of Outputs 4, Timers Programmable, Yes Clock, No Display Display, Port Type Ethernet, Non isolated serial link serial, USB port mini, Memory 64 MB RAM, 8 MB

Item: Logic Controller
Input Voltage: 100 to 240V AC
Output Type: Relay
Amps: 2.0 A
Number of Outputs: 4
Clock: Yes
Display: No Display
Number of Inputs: 14
Description/Special Features: Controller M241 24 IO relay Ethernet, protection type Short-circuit protection transistor output, Short-circuit and overload protection with automatic reset transistor output, Reverse polarity protection transistor output, Without protection relay output, application structure 8 external event tasks, 3 cyclic master tasks + 1 freewheeling task, 8 event tasks, 4 cyclic master tasks, mounting support Top hat type TH35-15 rail IEC 60715, Top hat type TH35-7.5 rail IEC 60715, plate or panel with fixing kit, relative humidity 10¿95 %, without condensation in operation), 10¿95 %, without condensation in storage), operating altitude 0...6561.68 ft (0...2000 m), Discount Schedule MSX, Environmental Disclosure Product Environmental Profile
Port Type: Ethernet, Non isolated serial link serial, USB port mini
Memory: 64 MB, 8 MB
Depth: 3.74 in
Timers: Programmable
Slots: Ethernet RJ45, Non isolated serial link serial 1 RJ45 RS232/RS485, Non isolated serial link serial 2 removable screw terminal block RS485, USB port mini B USB 2.0
Width: 5.91 in
Height: 3.54 in
Country of Origin (subject to change): Indonesia

Logic Controller, 100 to 240VAC
