Photoelectric-Sensor-Rectangular-Diffuse-E3T-FD13

Photoelectric Sensor, Rectangular, Diffuse

Omron Part No : E3T-FD13

Item: Photoelectric Sensor

Circuit Type: PNP

Sensing Method - Rectangular Photoelectric Sensor: Diffuse

Description
Specifications

Photoelectric Sensor, Shape - Rectangular Photoelectric Sensor Rectangular, Sensing Method - Rectangular Photoelectric Sensor Diffuse, Power Requirement - Rectangular Photoelectric Sensor 12 to 24V DC, Output Circuit Type - Rectangular Photoelectric Sensor PNP, Operating Mode - Photoelectric Sensor Light On, Max. Sensing Distance - Rectangular Photoelectric Sensor 30 mm, Electrical Connection - Rectangular Photoelectric Sensor 2m Cable, Height - Rectangular Photoelectric Sensor 24 mm

Circuit Type: PNP
Sensing Method - Rectangular Photoelectric Sensor: Diffuse
IP Rating: 67
Power Requirement - Rectangular Photoelectric Sensor: 12 to 24V DC
Width: 0.28"
Output Circuit Type - Rectangular Photoelectric Sensor: PNP
Depth: 0.43"
Operating Mode - Photoelectric Sensor: Light On
Max. Sensing Distance - Rectangular Photoelectric Sensor: 30 mm
Max. Load Current: 50 mA
Electrical Connection - Rectangular Photoelectric Sensor: 2m Cable
Electrical Connection: 2m cable
Height - Rectangular Photoelectric Sensor: 24 mm
Operation Mode: Light On
Standards: CE Approval
Max. Sensing Distance: 30mm
Power Requirement: 12 to 24VDC
Min. Object Size: 0.15mm dia
Operating Temp. Range: -25 Degrees to 55 Degrees C
Width - Rectangular Photoelectric Sensor: 7 mm
Footnotes: 4
Light Source: Red LED
Body Material: PBT
Shape: Rectangular
Features: Output Short-Cut And Output Reverse Polarity Protection, Surge Suppressor
Length: 0.94"
Response Time: 1.0 msec
Depth - Rectangular Photoelectric Sensor: 11 mm
Sensing Method: Diffuse

Photoelectric Sensor, Rectangular, Diffuse
